Chanzon BDW94C TO-220 Darlington Transistor, PNP

Key Features:- PNP Transistor with a robust design for various applications. - Collector-Emitter Voltage (VCEO): Matches VCBO ratings. - Continuous Collector Current (IC): Up to 6A. - Collector Power Dissipation (PC): 2W. - Storage Temperature Range (Tstg): -55°C to +150°C. - Collector-Emitter Breakdown Voltage (V(BR)CEO): Also varies from -40V to -100V. - Collector Cut-Off Current (ICBO): Below 0.7 mA for all variants at specified conditions. - Emitter Cut-Off Current (IEBO): -1 mA. - Collector-Emitter Saturation Voltage (VCE(sat)): -1.5V at 6A, 0.6A base current. - Base-Emitter Voltage (VBE): -2V at 6A collector current. - Transition Frequency (fT): 3MHz at specified conditions. Transistor Type: Power PNP Darlington Bipolar Junction Transistor. Application: Suitable for a wide range of electronic circuit uses including power regulation, motor control, and signal amplification. Package: Pack of 10 transistors in an Anti-Static bag for electrostatic protection, ESD safety, and extended shelf life.
