100TECH Stainless Steel Fule Tank Sending

-Empty oil level 0 ohm, Full oil level 190 ohm. 240-33 ohm sensors can only be applied to 240-33 ohm fuel gauge. -Empty oil level 240 ohm, Full oil level 33 ohm. The sensor can not be connected to the power supply, can not be connected to the positive electrode, does not need to be connected to the power supply, it is connected with the gauge signal directly Specifications: - Protection ank: IP67 - Resolution range: 10-21 mm - Assembly: SAE standard 5 holes - Rated current for alarm switch: 500mA - Output signal: 240~33 ohm or 0-190ohms for you choose - Operating temperatures: - 40 to 85 Celsius - Fit for Fuel Level Gauge and Water Level Gauge - Mounting: 5 pieces of M5 screws and 2 mm thick gasket 0-190 ohms: 0 ohms at empty, 190 ohms at full. Easy to install The fuel sending unit comes with 1 x Sensor, 1 x Gasket, 5 x Screws and 1 x instructions. [Material]: Fuel tank sending unit is made with heavy duty stainless steel. This water level sensor is reed switch, durability and reliability, steady output signal. No adjustment needed for tank [Wide Application]: The fuel level sender is suitable for Boat, Auto,Trucks, Buses and Marine field. Fit for Fuel Level Gauge,Water Level Gauge and any kinds of liquids without impurities The Fule/Water Level Sensor with American standard output 240-33 ohms (240 ohms at empty, 33 ohms at full). The fuel sending unit comes with 1 x Sensor, 1 x Gasket, 5 x Screws and 1 x instructions [Easy to Install]: SAE 5 hole mounting pattern, easy to install and hookup.
